Productions



We Are Committed To Providing High-Quality Functional Co Extruded Films For Various Industries

THERMOFORMING

Description

Thermoforming film is used as bottom film together with top film to pack products on thermoforming machines.

Through the 11-layer  co-extrusion machine, various raw materials are extruded and molded, offering superior flatness compared to blown film products. With excellent heat stretchability, it adapts to various products, boasting high transparency and excellent appearance display effects

Parameter
Advantage

Tape casting process

Compared to the blown film process, the casting process more effectively ensures the flatness and tensile properties of the film.

Eco-friendly co-extrusion

The casting co-extrusion process eliminates the use of organic binders, rendering it more environmentally friendly and leaving no residues.

Multiple specifications

Offers solutions with varying thicknesses and coefficients of friction, compatible with mainstream brands of bag-making, thermoforming and heat-sealing machines.

Easy-Peeling

Provide solutions for easy tearing and peeling, facilitating customers to effortlessly open the packaging


Adapt to the environment

Offers solutions for high-temperature retorting and low-temperature refrigeration, adapting to a variety of environmental requirements.

The display effect is exceptionally impressive

It exhibits exceptional transparency and visual display effectiveness

A variety of raw material combinations

The integration of raw materials with diverse physical properties is employed to furnish the requisite characteristics for the surface layer, barrier layer, and heat-seal layer.

Excellent tensile properties

Utilizing the superior tensile properties of materials such as PA, the product is molded through either blow molding or vacuum forming.

Accommodates a variety of shapes

After the film is stretched and molded, it can adapt to the shapes and contours of various products.

Excellent physical characteristics

It possesses a balanced barrier property against oxygen and water vapor, along with excellent heat-sealing strength, mechanical strength, and durability.

  • Advised heat  sealing temperature:130°C~140°C



    heat sealingtime:1s~1.5s



    thermo forming temperature 85°C~105°C.



    Best usage packaging for food saved above-70°C,



    or food sterilized under100°C.

  • Advised heat sealing tempera-ture:145℃~160°℃,



    heat sealing time:1s~1.5s,



    thermoforming temperature105℃~115℃.



    Best usage food sterilized at 121℃ in 30min.






  • Advised heat sealing temperature:130℃~140℃,



    heat sealing time:1s~1.5s,



    thermo-forming temperature85℃~105℃.



    Best usage packaging for fresh food stuff such as meat saved at 0℃~10℃, or food sterilized under 100℃






  • Advised heat sealing temperature:145℃~160°℃,



    heatsealing time:1s~1.5s,



    thermoforming temperature 105℃-115°℃.



    Best usage packaging for food sterilized at121℃ in 30min,and demands a longshelf life.






  • Advised heat sealing temperature at a low temperature of 90℃,



    heat sealingtime:1s-1.5s,



    co-extruded PE/TIE/EVOH/TIE/PEfilm laminated with BOPE used as recycle bag making film or top lidding film.

    Can be used for liquid,frozen,frozen packaging.suitablefor pasteurization,hot filling.high pressure processing,iradiation,microwave steril-ization method of safety sterilization.

    Also suitable for freezerstorage,air and vacuum seal.The appearance is more flatnot easy to cur,smoothand beautifuL

  •

    Advised heat sealing temperature:145℃-160℃,



    heat sealing time:1s-1.5s,



    thermoforming temperature 105℃-115℃.



    Bet usage packaging for food sterilized at 121℃ in 30min and demands a long shelf life



    The easy peeling property enhances the omfort of  usage.




  • Advised heat sealing temperature:135℃~140°℃,



    heatsealingtime:1s~1.5s,



    thermoforming temperature85℃~100℃.



    Bestusage packaging forfresh food stuff such as meat saved at 0℃~10℃,or food sterilized under 105℃



    The easy-peeling property enhances the comfort ofusage.






  • Advised heat sealing temperature:135℃~140°℃,



    heatsealingtime:1s~1.5s,



    thermoforming temperature85℃~100℃.



    Bestusage packaging forfresh food stuff such as meat saved at 0℃~10℃,or food sterilized under 105℃



    The easy-peeling property enhances the comfort ofusage.






  • The skin film is an easy to openfilm with a strong.consistentpeel,improving the convenience of customers when theyneed to eat the product.Thetight seal also prevents the con-tents from movingduringstorageand transportation,ensur-ing that the productcontinues to lookits best.Itcan be easilyused on fresh,frozen and processedfoodsandis suitableformicrowave cooking. Skin film is also suitablefor a variety of pallet types and ava-riety of products,makingitavery popular film forawiderange of customers.
